Name: Custom Pcb Board Solar Inverter Circuit Board One-Stop Manufacturing Service From Factory Product Category PCB & PCBA
Brand: Shenzhen XZJ Technology Co., Ltd.
SKU: XZJ-Pcba
Availability: InStock

Home Products Multilayer PCB

Custom Pcb Board Solar Inverter Circuit Board One-Stop Manufacturing Service From Factory Product Category PCB & PCBA

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	XZJ
Model Number:	XZJ-Pcba

Contact Now

Detailed Product Description

Base Material:	Multilayer Pcb	Copper Thickness:	0.5oz-5oz
Board Thickness:	1.6mm	Min. Hole Size:	0.1mm
Min. Line Width:	0.075mm	Min. Line Spacing:	0.075mm
Functional Application:	Embedded Processing	Surface Finishing:	HASL
Board Size:	HASL, Enig, OSP, Immersion Au, AG, Sn, Customized BMS PCB Modules	Type:	Pcb Board
Material:	FR4/94v0/Aluminum/cem-1 Cem-3, FR4/94v0/Aluminum/cem-1 Cem-3	Product Name:	Pcb Board Assembly
Service:	PCB+components+assembly	PCBA Service:	SMD SMT DIP Component Assembly
